What's in the Course | Promo
This Course Includes
- 4 hours on-demand video
- 42+ Lessons
- 5 articles
- 2 downloadable resources
- Full lifetime access
- Certificate of Completion
- Access on mobile
- Included Software: Siemens TIA Portal & WinCC Professional (21-Days Trial), Kepserver (Free Demo), SQL Server (Free Demo), Factory I/O (30 Days Trial)
What you'll learn
- Students will learn advanced hardware and communication with Siemens S7-1200 PLC and TIA Portal
- Siemens S7-1200 PLC to PLC Communication using Profinet Interface
- IFM IO-Link Communication with Siemens S7-1200 PLC
- Interfacing OPC Server (Kepserver) with TIA Portal and reading/writing OPC Tags
- Creating PC Based HMI Runtime using WinCC Advanced
- Interfacing SQL Database for creating historical log or relational database
- Students must complete Siemens TIA Portal Level 1 Course and having a physical S7-1200 PLC would help learn hands-on
Requirements
- Basic knowledge of Siemens PLC and TIA Portal
- Siemens S7-1200 PLC & TIA Portal Level-1 Course by Muhammad Awais
Course Description
This course is for the system integrators or automation engineers looking to automate machines, production lines or plant on the shop floor. The content described above will give you the hands on experience on working with multiple PLCs of the same brand, or with different brands using OPC, creating Profinet, Fieldbus and using point to point IO Link devices then centralizing the process using PC Based HMI.
This course is hardware intensive and most tasks are performed using physical PLCs or IO Link devices so it’s for all those who have to deal with lots of hardware or automation on the job or for the client, it's time to step up the game.
Course Content
- Siemens S7-1200 PLC to PLC Ethernet Communication using Profinet Interface
- IFM IO-Link Communication with S7-1200 PLC
- WinCC Advanced HMI (PC Based HMI) and Creating Runtime
- Understanding and Interfacing OPC Server (Kepserver) with TIA Portal and WinCC Advanced
- Understanding and Interfacing SQL Database with TIA Portal and WinCC Advanced
Software's
- Siemens TIA Portal and WinCC Advanced (21-Days Trial Version Provided)
- Kepserver (Free Demo Provided)
- SQL Server (Free Demo Provided
- Factory I/O (30-Days Trial Version Provided)
Deliverable
- Training Lectures
- Free Software’s – Trial
- Lifetime Access to the course
Who this course is for:
- Automation Engineers
- System Integrators
- Engineering Students
- Controls Engineers
- Plant Engineers
- Electrical Engineers
Example Curriculum
- Lesson 1 - PLC - PLC Communication Overview (1:12)
- Lesson 2 - Setting up Hardware and IP Addressing (1:44)
- Lesson 3 - Hardware Configuration (6:27)
- Lesson 4 - Sending Data from PLC-1 to PLC-2 (7:10)
- Lesson 5 - Operating Output of PLC-2 from PLC-1 (6:41)
- Lesson 6 - Automatic Requests using Clock Memory (3:02)
- Lesson 7 - Operating PLC-1 from PLC-2 (5:19)
- Lesson 8 - Exchanging Data using Global DBs (11:52)
- Lesson 9 - Receiving Data (4:37)
- Profinet Manuals
Rana Muhamamd Awais
Course Instructor
Rana Muhammad Awais is a Professional Electrical & Automation Engineer with over 06 years of experience in process, manufacturing, RnD and services industries in the fields of Industrial Automation, IIoT, Productivity, Projects and Maintenance.
He has completed over 50 automation projects including major plants and machines automation using PLC / DCS / SCADA and IIoT Systems of different brands such as Siemens, Allen Bradley, ABB, Wonderware, Ignition, Mitsubishi, Delta, Fatek, B&R, IFM and more.
Automation Play is a result of his passion and interest to share his learning’s and experience at one place to the world and equip them with Industry 4.0 and Industrial Automation Skill set.
